1501-KDNB016-020-24DC | 1/4' N.C. Vacuum Direct Acting NBR 1-16 Bar 24VDC 10W
Log in to see prices here
1/4" Solenoid Valve N.C. Vacuum Direct Acting NBR -1 - 16 Bar 24V DC 10 W
Product information
- Product code 1501-KDNB016-020-24DC
- Brand GEVAXView all GEVAX products
- Remaining stock Only 999 left
| Valve Type | Vacuum Valves |
|---|---|
| Connection Size | 1/4" |
| Number of Paths | 2/2 |
| Position | Normally Closed |
| Working Principle | Direct Acting |
| Gasket & Diaphragm | NBR |
| Min. Pressure (bar) | -1 |
| Max. Pressure (bar) | 16 |
| Orifice Size (mm) | 2 |
| Temperature (°C) | -10°C +80°C |
| Coil Brand | Amisco |
| Coil Voltage | 24V DC |
| Coil Power | 10 W |
| Body Material | Brass |
| KV Value | 1.7 l/min |
| Tracking Number | 07VC |
| Coil Type | TP1 |
| Product Weight (kg.) | 0.31 |
