1901-KDNB016-015-24DC | 1/4" N.C. Direct Acting NBR 0-16 Bar 24VDC 10W
Log in to see prices here
1/4" Solenoid Valve N.C. Direct Acting NBR 0 - 16 Bar 24V DC 10 W
Product information
- Product code 1901-KDNB016-015-24DC
- Brand GEVAXView all GEVAX products
- Remaining stock Only 999 left
| Valve Type | General Purpose Valves |
|---|---|
| Connection Size | 1/4" |
| Number of Paths | 2/2 |
| Position | Normally Closed |
| Working Principle | Direct Acting |
| Gasket & Diaphragm | NBR |
| Min. Pressure (bar) | 0 bar |
| Max. Pressure (bar) | 16 |
| Orifice Size (mm) | 1.5 |
| Temperature (°C) | -10°C +80°C |
| Coil Brand | Amisco |
| Coil Voltage | 24V DC |
| Coil Power | 10 W |
| Body Material | Brass |
| Drawing and Image No. | 1 |
| KV Value | 1 l/min |
| Tracking Number | 03AC |
| Coil Type | TP1 |
| Product Weight (kg.) | 0.31 |
