4911C-ABPD010-120-12DC | 1/2" Solenoid Valve N.O. Nickel Plated Piston Steam Pilot Operated PTFE 0.5 - 10 Bar 12V DC 17 W
Log in to see prices here
1/2" Solenoid Valve N.O. Nickel Plated Piston Steam Pilot Operated PTFE 0.5 - 10 Bar 12V DC 17 W
Product information
- Product code 4911C-ABPD010-120-12DC
- Brand GEVAXView all GEVAX products
- Remaining stock Only 999 left
| Valve Type | Steam Valves |
|---|---|
| Connection Size | 1/2" |
| Number of Paths | 2/2 |
| Position | Normally Open |
| Working Principle | Pilot Operated |
| Gasket & Diaphragm | PTFE |
| Min. Pressure (bar) | 0.5 |
| Max. Pressure (bar) | 10 |
| Orifice Size (mm) | 12 |
| Temperature (°C) | -10°C +180°C |
| Coil Brand | Amisco |
| Coil Voltage | 12V DC |
| Coil Power | 17 W |
| Body Material | Nickel Plated Brass |
| KV Value | 65 l/min |
| Tracking Number | 72SH |
| Coil Type | TP4 |
| Product Weight (kg.) | 0.755 |
