5871-KDVB008-020-24DC | 1/4" NPT N.C. Stainless Steel Ex-Proof Direct Acting FKM 0 - 8 Bar 24V DC 3 W
Log in to see prices here
1/4" NPT Solenoid Valve N.C. Stainless Steel Ex-Proof Direct Acting FKM 0 - 8 Bar 24V DC 3 W
The prominent features of the stainless steel body normally closed ex-proof solenoid valve you are reviewing: Corrosion-resistant stainless steel body and internal parts, energy-efficient. Air, Water, Gas, Vacuum, Chemical, Hot Water, Natural Gas, LPG & LNG Recommended for use in applications such as etc. Zero Differantial Pressure works on systems.
The usage area where the product is frequently preferred is; Automotive, Textile, Irrigation, Cooling, Washing Machines, Machining Process, Recycling, Water Treatment, Paint Industry
Product information
- Product code 5871-KDVR008-020-24DC
- Brand GEVAXView all GEVAX products
- Remaining stock Only 999 left
| Valve Type | Ex-Proof Valves |
|---|---|
| Connection Size | 1/4" NPT |
| Number of Paths | 2/2 |
| Position | Normally Closed |
| Working Principle | Direct Acting |
| Gasket & Diaphragm | FKM |
| Min. Pressure (bar) | 0 bar |
| Max. Pressure (bar) | 8 |
| Orifice Size (mm) | 2 |
| Temperature (°C) | -10°C +150°C |
| Coil Brand | Amisco |
| Coil Voltage | 24V DC |
| Coil Power | 3 W |
| Body Material | Stainlees Steels |
| KV Value | 1.7 l/min |
| Tracking Number | 14EC |
| Coil Type | TP7 |
| Product Weight (kg.) | 0.47 |
